PIR (Polyisocyanurate foam)

PIR polyisocyanurate foam

PIR polyisocyanurate is a kind of foaming material made from the reaction of polyether and isocyanate after catalysis reaction.It excels common polyaminoester foaming material in physical behavior and flame resistance.It is an ideal organic low temperature heat insulation material.Its thermal conductivity is very low ,with light weight and shockproofing .It can be made into prefabrications in-site freely according to a client.It is widely used in oil refining ,chemical industry, ethylene production and storage,chemical fertilizer, cold storage and construction industry ,etc. It can be in pipe and slab. Our insulation materials are asbestos free. No chlorofluorocarbon (CFCs) or Hydrochlorofluorocarbon (HCFCs) be used in the production of our insulation. It can be covered aluminium foil, glass fibe cloth or others. It can meet ASTM C 591-17.

1.B1, B2 fire rate

2.Working temperature scope is –196℃~200℃

3.Excellent dimension stability

4.Can be prefabricated freely according to customers requirement

Data Sheet of PIR Properties
Item	Unit	Technical Date	Testing Method
Density(Normal Temp.)	kg/m3	35-55	ASTM D1622/GB6343
Thermal Conductivity
40℃	W/m.k	≤0.023	ASTM C518 C177/GB10294
20℃	W/m.k	≤0.021
10℃	W/m.k	≤0.020
0℃	W/m.k	≤0.019
-10℃	W/m.k	≤0.019
-20℃	W/m.k	≤0.018
-30℃	W/m.k	≤0.018
-50℃	W/m.k	≤0.019
-100℃	W/m.k	≤0.018
-120℃	W/m.k	≤0.017
-160℃	W/m.k	≤0.015
Water vapor permeability	Ng/Pa.m.s	≤2.5	ASTM C534 E96/GB/T17146
Water absorption	% (by vol.)	≤0.3	ASTM C272/GB/Z228
Closed Cell Rate	%	≥98	ASTM D6226
Compressive Strength	kPa	≥320	ASTM D1621-2016/GB8813
Flexural Strength	kPa	≥396	ASTM 1623-2017/GB/T8812
Scope Temp.Service	℃	-196～+200	ASTM E228
Oxygen Index	%	≥43	ASTM D2863/GB2406
Fire Resistance		B1	GB8624
Flame spread max		<13	ASTM E84
Vertical Combustion Method	Average Combustion Time	≤21	GB8333
Vertical Combustion Method	average combustion height(mm)	≤250	GB8333
