Foam glass insulation

                             Foam Glass Insulation


Foam glass (Cellular glass): Cellular glass takes glass dust as the basic material. Adds foaming agent and roasts into being through tunnel kiln. It is the best low-temperature heat-insulation material at present in the world markets. It is noted for its low unit weight, minor thermal conductivity, anti-moisture absorption, anti-mouldy, high mechanical strength, easy processing, resisting acid corrosion(except HF), nonpoisonous, stable chemical function, able to be used in a wide scope from extreme low to high temperature. Its excellent heat-insulation property can be last for many years without any degenerating. More important is that celluar glass itself is fireproof and shockproof. When it is used under such bad situations as extreme coldness, under-earth, open, easily fired, easily be damp and having chemical corrodent. It is not only safe but durable. It is be called "permanent heat-insulation material that not need be replaced" So it is widely used in oil chemistry, cold storehouse, under-earth project, ship-building, national defence and military project etc.

Properties

Physical Index

Item

Unit

EASTM

ASTM-C552-15

Type


CG-120-160


Density

kg/m3

120-160

98-170

Maximum use temperature

 -273~+550

 -268~+427

Thermal conductivity         W/m K  at

204

0.086

0.090

149

0.072

0.075

93

0.055

0.063

38

0.048

0.053

24

0.042

0.051

10

0.040

0.049

-18

0.036

0.045

-46

0.035

0.042

-73

0.032

0.039

-101

0.026

0.037

Flexural strength

kpa

≥628

≥283-627

Compressive strength

kpa

≥965

≥414-1655

Linear expansion coefficient:

Wm/m

<8.1X10-6

<9X10-6

Moisture absorption rate

%

0.00


Water absorption rate per Volume

%

0.2

0.5

Soft temperature

600


Melting point

1200


Combustibility & reaction to fire

Noncombustible - will not burn,                    Flame spread 0,                                                   Smoke development 0


Color

Gray black


Others

Accord with ASTM-C552-15


Standard size and packaging and Dimension tolerance

Class

Items

Sizes

Tolerances

Pipe section or slab

Length (mm)

300-1000

+3, -2

Width(mm)

200-600

+3, -2

Inside diameter (mm)

16---3560

+3, -2

Thickness (mm)

25---180

+3, -2

Standard packaging

Polythene bags inside and Cardboard cartons outside
