Fiberglass needled mat

                                   Glassfiber Needled Mat


Product Introduction

GLASSFIBER NEEDLED MAT is an advanced material for air cleaning and thermal insulation made by cutting continuous glass fibers into given length and then felting them through a process of filamentizing, napping and needling. Characterized by high temperature resistance, good thermal insulation, superior acoustic absorptivity and high efficiency of cleaning tail gas. It has found wide application in mechanical, electrical, chemical, metallurgical, petroleum, coal, building and traffic industries, suitable for the use as sandwiched heat and sound insulation system in automobile, ship, and train carriages. When treated with a ternary rare-earth cleaning catalyst, it is an ideal material for tail gas cleaning and sound deadening for cars and motorcycles.

Material


E-glass fiber

Specification

Density

184kgs/m3

thickness

6-25mm

Size L x W

2m-20m

Physical properties

Thermal Conductivity

0.03W/mk

Fireproof

anti-flaming (grade A)

Moistureproof

98.5%

Anticorrosiveness

inoganic material is not needed

Sound Absorption

above 0.75LRC

Weather and water resistance

OK

Non-combustible material

OK

Sewing threads shall not decompose in a typical offshore marine environment or at the operating temperature.

Applicable Temperature

-120  +650

Fire resistance (when tested in accordance with AS1530 Part 3-1989, Early Fire Hazard indixes:)

Ignitability

0

Spread of Flame

0

Heat evolved

0

Smoke developed

0

Corrosion resistance

pH

7.0-8.0

Glass fiber

Non-asbestos

Finish Type

Needled

Color

White
