Product categories and Product usage:

1.Direct Roving for Continuous Fiber Reinforced Thermoplastics is used for CFRT process.Fiberglass yarns were outside unwound from the bobbins on the shelf and then arranged in the same direction; Yarns were dispersed by tension and heated by hot air or IR; Molten thermoplastic compound was provided by an extruder and impregnated the fiberglass by pressure; After cooling, the final CFRT sheet was formed.

2.Long fiber injection process (PU-LFI) is a relatively new process technology for reinforced PU composites. E-glass LFI roving is compatible with reinforced polyurethane resin, has excellent runnability even at high speed, good choppability and dispersion, and can be used to produce motorboat hull and automotive exterior  parts, etc.

3.Assembled Roving for Filament Winding is specially designed for FRP filament winding process, compatible with unsaturated polyester.
Its final composite product delivers excellent mechanical property, and is mainly used to manufacture storage vessels and pipes in petroleum, chemical and mining industries.

4.EA514 assembled roving is specially designed to reinforce for gypsum. It is chopped into a specific length, then mixed with gypsum, starch powder and accelerating agent to form a light weight construction boards, delivering good choppability, low static and high strength of end products.

5.E-Glass Woven Rovings are bidirectional fabric made by interweaving direct rovings.
E-Glass Woven Rovings are compatible with unsaturated polyester, vinyl ester, epoxy and phenolic resins.
E-Glass Woven Rovings are a high-performance reinforcement widely used in hand lay up and robot processes to manufacture boats, vessels, plane and automotive parts, furniture and sports facilities.

6.E-Glass Texturized Roving is compatible with PF, EP and UP resins.
It features as uniform texturizing and high absorbability; it is used to manufacture thermal insulation and acoustic insulation products.

7. EACompofil is a high performance roving made of interwound continuous glass fiber and thermoplastic fiber. It can be used to manufacture thermoplastic composites directly with no need for extra resin. It is suitable for various molding processes including mold pressing, vacuum molding, filament winding and more. The applications of this product include Military, automotive, construction, sports and new energy industries.

8.Direct Roving for Filament winding is compatible with unsaturated polyester, polyurethane, vinyl ester, epoxy and phenolic resins.
Main uses include manufacture of FRP pipes of various diameters, high-pressure pipes for petroleum transitions, pressure vessels, storage tanks, and, insulation materials such as utility rods and insulation tube.

9.Direct Roving for Pultrusion is compatible with unsaturated polyester, vinyl ester, epoxy and phenolic resins, and is widely used in building & construction, telecommunication and insulator industry.

10.Direct Roving for weaving is compatible with unsaturated polyester, vinyl ester and epoxy resins.
Its excellent weaving property makes it suited for fiberglass product, such as roving cloth, combination mats, stitched mat, multi-axial fabric, geotextiles, molded grating.
The end-use products are widely used in building & construction, wind power and yacht applications.

11.Direct Roving for LFT is coated with a silane-based sizing compatible with PA, PBT, PET, PP, ABS, PPS and POM resins.
It is widely used in industries of automotive, electromechanical, home appliance, building & construction, electronic & electrical, and aerospace.

12.Assembled Panel Roving is coated with a silane-based sizing compatible with UP. It can wet out fast in resin and deliver excellent dispersion after chopping.
The panel made from it delivers properties:light weight,high strength,excellent impact resistance,no white fiber,high translucency.It can be used to manufacture lighting boards in building & construction industry.

13.EA162 Assembled Roving for Chopping is coated with special silane-based sizing, compatible with UP and VE, delivering relatively high resin absorbability and excellent choppability, while its final composite products deliver superior water resistance and excellent chemical corrosion resistance. It is typically used to manufacture FRP pipes.

14.Assembled Roving for spray-up is compatible with UP and VE resins.
It delivers properties of low static, excellent dispersion, and good wet out in resins.
It covers a wide range of applications: bathtub, FRP boat hulls, various pipes, storage vessels and cooling towers.

15.Assembled Roving for SMC is compatible with unsaturated polyester, vinyl ester resin, delivering good dispersion after chopping, low fuzz, fast wet out and low static.
Its end use applications cover:
Automotive parts: bumper, rear cover box, car door, headliner;
Building & construction industry: SMC door, chair, sanitary ware, water tank, ceiling;
Electronic & electrical industry: a variety of parts.
In recreation industry: a variety of apparatus.

16.Assembled Roving for CSM

17.E-Glass Assembled Roving for GMT is based on special sizing formulation, compatible with modified PP resin.
Its features as follows:
moderate fiber stiffness,
excellent ribbonization and dispersion in resin,
excellent mechanical and electrical property.
The GMT sheet is a kind of structural material, widely used in the sector of automotive, building & construction, packing, electrical equipment, chemical industry and sport.

18.Chopped Strands for BMC are compatible with unsaturated polyester, epoxy resin and phenolic resins.
The end-use applications include transportation, building & construction, electronic & electrical, mechanical, and light industry.

Product Features

1.Even tension,excellent chopped performance and dispersion,good flow ability under mold press.

2.Fast and complete wet-out.

3.Low static,no fuzz.

4.High mechanical strength.

5.Good process performance and low fuzz

6.Compatibility with multiple resins systems

7.Others

Product Characteristics

High intensity,Corrosion resistance,Heat resistance,Mositure absorption less

Electrical insulating performance is good

Data sheet

Item

Unit

Data

Breakage Strength

N/Tex

>0.3,≥0.5, >2.5, or others

Size Content

%

0.3 ~ 2

Linear density(Yarn dia.)

Tex

180-9600

Linear Density (%)

%

+5,-5

Diameter of filament

μm

12-31

Sizing(Binding material)

Paraffin/Silane/ Starch/others

Moisture content

%

≤0.10

Glass typle

mm

E or others

Temp.resistance

℃

550

Stiffness

mm

110 ~ 170 (+20,-20)
