Fiberglass yarn is electrical insulation materials, electronic industrial fabrics ,tubes and other industrial fabric raw materials. It is widely used for weaving all kinds of fabrics in the scope of reinforcement,  insulation, corrosion resis-tance,heat resistance and so on.

Fiberglass yarn is made from 5-9um fiberglass filament which are then gathered and twisted into one finished yarn.

Glass fiber yarn is necessary raw material for all kinds of insulation products, engineering material and electric industry. Ending product of Glassfiber yarn: such as, electronic grade fabric, fiberglass sleeving and so on, E glass twsited yarn is characterized by its high strength, corrosion resistance, heat resistance, low fuzz and low moisture absorption.

Specification:

1)      Fiberglass yarn use glass sphere  as raw material

2)      It is insulation, high intensity,corrosion resistance, high temperature resistance,low water absorption,etc.

3)      It is necessary material of all kinds of insulation products and industry yarn.

4)      Specification:6tex,12tex,27tex,33tex,others, normally 1-strand,2strand,3strand,4strand,6strand,8strand or others

5)      Other specification can be produced per customers requirments

Product Characteristics

High intensity,Corrosion resistance,Heat resistance,Mositure absorption less

Electrical insulating performance is good

Product usage

Used for knitting cable coated layer, casing, the mine fuse, insulation materials of motor electric winding,all kinds of machine weaving yarn and other industrial yarn

Data sheet

Item

Unit

Data

Strength of Fiber

N/Tex

>2.5 to >54.4

Linear density(Yarn dia.)

Tex

>5.5

Diameter of filament

μm

5.5-16

Direction of twist

S or Z or others

Twist degree

T/m

28-280

Plied yarn

1 to 16

Sizing(Binding material)

Paraffin/Silane/ Starch/others

Moisture content

%

≤0.20

Glass typle

mm

E or C or others

Temp.resistance

℃

550
