Technical specifications： |
|
|
|
|
1、Ceramic fiber cloth and tape |
Classification Tempeature |
| 1260 |
|
|
Production | Ceramic fiber cloth | Ceramic fiber tape |
Code | EASTM-cfc1 | EASTM-cfc2 | EASTM-cft1 | EASTM-cft2 |
Service temperaure | 1000 | 1260 | 1000 | 1260 |
Basic material | Ceramic fiber | Ceramic fiber | Ceramic fiber | Ceramic fiber |
Reinforce | stainless steel | stainless steel | stainless steel | stainless steel |
Theoretical density (kg/M3) | 300-550 | 300-550 | 300-550 | 300-550 |
Specification(mm) | 1-6mm | 1-6mm | 1-6mm | 1-6mm |
Moisture content(%) |
|
| ≤2 |
|
Warp density |
|
| 48-60 piece/10cm |
|
Weft density |
|
| 21-30 piece/10cm |
|
Organic content(%) |
|
| ≤15 |
|
2、1260 Ceramic fiber round braided rope and square braided rope |
Braided rope are available in round and square form and are produced by plaiting ceramic fibre yarns around a central ceramic fibre core,resulting in a high strength,high density product with low compressibility.Each yarn is reinforced with a single filament glass fibre or alloy wire depending upon use temperature.These products are especialy recommended for heavy duty applications. |
Classification Tempeature |
| 1260 |
|
|
Production | Ceramic fiber round braide rope | Ceramic fiber square braided rope |
Code | EASTM-rbr1 | EASTM-rbr2 | EASTM-sbr1 | EASTM-sbr2 |
Service temperaure | 1000 | 1260 | 1000 | 1260 |
Basic material | Ceramic fiber | Ceramic fiber | Ceramic fiber | Ceramic fiber |
Reinforce | stainless steel | stainless steel | stainless steel | stainless steel |
Theoretical density (kg/M3) | 300-550 | 300-550 | 300-550 | 300-550 |
Specification(mm) | according to the requirement of clients |
Moisture content(%) |
|
| ≤2 |
|
Delivery state |
|
| roll |
|
Organic content(%) |
|
| ≤15 |
|
3、1260 Ceramic fiber twisted rope |
Twisted rope consists of a multiple of ceramic yarn strands which can be either fiberglass or stainless steel reinforced with a single filament glass fibre or alloy wire depending upon use temperature.These products are especially recommended for heavy duty applications. |
Classification Tempeature |
| 1260 |
|
|
Production | Ceramic fiber round twisted rope | Ceramic fiber square twisted rope |
Code | EASTM-rtr1 | EASTM-rtr2 | EASTM-str1 | EASTM-str2 |
Service temperaure | 1000 | 1260 | 1000 | 1260 |
Basic material | Ceramic fiber | Ceramic fiber | Ceramic fiber | Ceramic fiber |
Reinforce | stainless steel | stainless steel | stainless steel | stainless steel |
Theoretical density (kg/M3) | 300-550 | 300-550 | 300-550 | 300-550 |
Specification(mm) | according to the requirement of clients |
Moisture content(%) |
|
| ≤2 |
|
Delivery state |
|
| roll |
|
Organic content(%) |
|
| ≤15 |
|
4、Ceramic fiber yarn and sleeve |
Yarn is manufactured from ceramic fibre.This yarn is the base of all the ceramic textile range of products.The yarn is reinforced with either a fiberglass or a fine stainless steel. |
Sleeve are produced by converting ceramic blanket and by processing refractory ceramic fibre yarn into woven products. |
Classification Tempeature |
| 1260 |
|
|
Production | Ceramic fiber yarn | Ceramic fiber square twisted sleeve |
Code | EASTM-cfy |
| EASTM-csy |
|
Service temperaure | 1000 or 1260 |
| 1000 or 1260 |
|
Basic material | Ceramic fiber |
| Ceramic fiber |
|
Reinforce | stainless steel |
| stainless steel |
|
Specification(mm) | according to the requirement of clients |
Moisture content(%) |
|
| ≤2 |
|
Delivery state |
|
| Cheese winding |
|
Organic content(%) |
|
| ≤15 |
|
